The double-sided adhesive tape consists of a polyester film carrier that is coated on both sides with a modified acrylate adhesive which shows a very good resistance against UV radiation, temperature stress, chemicals and solvents as well as moisture. The shear-resistant adhesive also has excellent permanent adhesion to metal, paint and other high-energy plastic surfaces as well as good permanent adhesion to low-energy surfaces.
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
|---|---|---|
| Resistance to solvents and chemicals | Mineral oils, Greases, Aliphatic solvents, Weak acids, Salts and alkalis | with professional bonding | resistant against most |
| Temperature resistance |
Minimum temperature: -40 °C Maximum temperature: 120 °C |
1 h, central European normal climate, short-term up to +180 °C |
| Adhesive power | 18 N/25 mm | after 1 min, on stainless steel | FINAT TM 1, covered on one side with 0.05 mm polyester film, average value |
|---|---|---|
| 23 N/25 mm | after 20 min, on stainless steel | FINAT TM 1, covered on one side with 0.05 mm polyester film, average value | |
| 25 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, covered on one side with 0.05 mm polyester film, average value | |
| Initial adhesion (loop tack) | 28 N/25 mm | FINAT TM 9 |
| Maximum shear strength | 600 Hour(s) | at 23 °C, on stainless steel | FINAT TM 8, covered on one side with 0.05 mm polyester film |
| 10 Hour(s) | at 70 °C, on stainless steel | FINAT TM 8, covered on one side with 0.05 mm polyester film |
| Application temperature | Minimum temperature 15 °C |
|---|
| Adhesive covered side | Modified acrylate |
|---|---|
| Adhesive open side | Modified acrylate |
| Carrier |
Colour carrier: Transparent Carrier: PP film |
| Format | Roll, Cut | |
|---|---|---|
| Cutting roll width | 12 mm | |
| 15 mm | ||
| 19 mm | ||
| 25 mm | ||
| 30 mm | ||
| 38 mm | ||
| 50 mm | ||
| 60 mm | ||
| 75 mm | ||
| 100 mm | ||
| Standard width | 1000 mm | |
| 1260 mm | ||
| Standard length | 50 m |
