ORABOND® 1436

The double-sided adhesive tape consists of a polypropylene film carrier which is coated on both sides with a rubber adhesive. The highly ageing-resistant adhesive is covered with siliconised paper on both sides

Product information

Technical properties

Resistance

Shelf Life 1 Year(s) in original packaging, at 20 °C and 50 % relative humidity
Temperature resistance Minimum temperature: -20 °C
Maximum temperature: 70 °C
1 h, central European normal climate

Adhesive properties

Adhesive power 17 N/25 mm on stainless steel, after 1 min | Average value, FINAT TM 1, covered on one side with 0.05 mm polyester film
18 N/25 mm on stainless steel, after 1 min | Average value, FINAT TM 1, covered on one side with 0.05 mm polyester film
20 N/25 mm on stainless steel, after 1 min | Average value, FINAT TM 1, covered on one side with 0.05 mm polyester film
Maximum shear strength 72 Hour(s) on stainless steel, after 23 °C | Average value, FINAT TM 8, covered on one side with 0.05 mm polyester film
0.083 Hour(s) on stainless steel, after 70 °C | Average value, FINAT TM 8, covered on one side with 0.05 mm polyester film
Processing
Application temperature Minimum temperature 15 °C
Product Construction
Adhesive covered side Synthetic rubber
Adhesive open side Synthetic rubber
Carrier Colour carrier: Transparent
Carrier: PP film
Dimensions
Format Roll, Cut
Cutting roll width 38 mm
50 mm
Standard width 1200 mm
Standard length 25 m
50 m

Downloads

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2025-01-21.
