Technical data sheet - English (EN)
PDF, 142.34kB, 2 Pages
Highly-flexible special PVC film white, UV-stabilised, silk-gloss
ORAJET® 3451
Product information
Technical properties
Resistance
| Durability | 4 Year(s) | with vertical outdoor weathering, central European normal climate; unprinted |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, 72 h after adhesion on aluminium | resistant in short-term against most |
| Tensile strength |
Minimum tensile strength along: 15 MPa Minimum tensile strength across: 15 MPa |
EN ISO 527 |
| Seawater resistance | Tested | adhered on aluminium | after 100 h/23 °C no change, DIN 50022 |
Adhesive properties
| Adhesive power | 14 N/25 mm | after 24 h, on stainless steel | FINAT TM 1, average value |
|---|---|---|
| Adhesive | Permanent |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks, Inkjet printing with UV inks, Inkjet printing with latex inks |
|---|---|
| Application temperature | Minimum temperature 8 °C |
Product Construction
| Liner | PE-coated paper on both sides, siliconised on one side |
|---|---|
| Front material |
Thickness front material: 0.08 mm Front material: Special PVC film |
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.08 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll |
|---|---|
| Standard width | 1520 mm |
| 1370 mm | |
| Standard length | 50 m |
