Technical data sheet - English (EN)
PDF, 138.01kB, 2 Pages
Polymer PVC film, white or transparent with glossy surface. *on request
ORAJET® 3751
Product information
Technical properties
Resistance
| Durability | 8 Year(s) | with vertical outdoor weathering, central European normal climate; unprinted |
|---|---|---|
| Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
| Resistance to solvents and chemicals | Oils, Greases, Fuels, Aliphatic solvents, Weak acids, Salts and alkalis | at room temperature, 72 h after adhesion on aluminium | resistant in short-term against most |
| Tensile strength |
Minimum tensile strength along: 19 MPa Minimum tensile strength across: 19 MPa |
EN ISO 527 |
| Seawater resistance | Tested | adhered on aluminium | after 100 h/23 °C no change, DIN 50021 |
Adhesive properties
| Adhesive power | 18 N/25 mm | after 24 h, glass | FINAT TM 1, average value |
|---|---|---|
| Adhesive | Permanent | repositionable with permanent end adhesion |
Processing
| Recommended printing procedure | Inkjet printing with solvent-based inks |
|---|---|
| Application temperature | Minimum temperature 8 °C |
Product Construction
| Liner | PE-coated paper on both sides, siliconised on one side |
|---|---|
| Front material |
Thickness front material: 0.06 mm Front material: Polymer PVC film |
| Adhesive | Solvent-polyacrylate |
General
| Thickness | 0.06 mm | without protective liner and adhesive, average value |
|---|
Dimensions
| Format | Roll | |
|---|---|---|
| Standard width | 760 mm | only available in white |
| 1370 mm | only available in white | |
| 1520 mm | only available in white | |
| 1370 mm | only available in transparent | |
| Standard length | 50 m |
Downloads
Technical documents
Processing notes - English (EN)
PDF, 57.51kB, 2 Pages
Product information - English (EN)
PDF, 89.36kB, 1 Page
Our safety data sheets / product information consider the state of the SVHC list of 2025-01-21.
