Technical data sheet - English (EN)
PDF, 453.10kB, 3 Pages
ORALITE® 5810 High Intensity Grade is a highly reflective film designed for traffic signs and traffic management products. It offers excellent resistance to corrosion and solvents, and an expected durability of up to 10 years. The film ensures excellent nighttime visibility and is available in 7 different colours.
Resistance to cleaning agents | No change | adhered on aluminium | 8 h in detergent solution (0.5 % household cleaner) at room temperature and 65 °C |
---|---|---|
Durability | 10 Year(s) | unprinted, with professional processing, with vertical outdoor weathering, central European normal climate |
Shelf Life | 2 Year(s) | in original packaging, at 20 °C and 50 % relative humidity |
Adhesive power | 15 N/25 mm | after 24 h, on stainless steel | Average value, FINAT TM 1 |
---|---|---|
Adhesive | Permanent |
Recommended printing procedure | Screen printing, UV printing, Eco-solvent printing |
---|---|
Suitable substrate | Aluminium, Galvanised sheet steel, Metals |
Application temperature | Minimum temperature 10 °C |
Liner | One-sided silicon-coated PP film |
---|---|
Front material | Acrylic film |
Adhesive | Solvent-polyacrylate |
Thickness | 0.28 mm | Average value, without protective paper |
---|
Reflective Technology | Glass bead |
---|---|
Reflectivity Compliance | Reflective film structure: Design B |
Reflectivity classes: RA2 |
Format | Roll |
---|---|
Standard width | 1235 mm |
920 mm | |
760 mm | |
610 mm | |
Standard length | 50 m |
