ORALITE® 5931M
Prismatic Construction Grade

ORALITE® 5931M Prismatic Construction Grade offers excellent reflective properties (RA2, design C) and is ideal for roadworks markings and traffic signs. The film is particularly weather-resistant and guarantees a durability of 5 years in outdoor use. Thanks to its single-layer structure, it protects against dirt accumulation at the edges and ensures excellent adhesion to polyolefin surfaces. Available in a hatched version and can be printed on request.

  • Excellent reflective prismatic film: Optimum reflective properties in accordance with reflection class RA2, design C
  • Certified quality: The film complies with EN 12899-1, the colour White/Red is also BASt-certified
  • Dirt-repellent structure: Single-layer structure to protect against dirt accumulation at the edges
  • Durability and weather resistance: 5 years durability in outdoor use

Product information

Technical properties

Resistance

Resistance to cleaning agents No change adhered on aluminium | 9 h in detergent solution (0.5 % household cleaning agent) at room temperature and 65 °C
Durability 5 Year(s) with professional processing, with vertical outdoor weathering, central European normal climate
Shelf Life 1 Year(s) in original packaging, at 20 °C and 50 % relative humidity

Adhesive properties

Adhesive power 15 N/25 mm after 24 h, on stainless steel | Average value, FINAT TM 1
Adhesive Permanent
Processing
Recommended printing procedure Screen printing
Suitable substrate Polyolefin substrates
Application temperature Minimum temperature 10 °C
Product Construction
Liner PE-coated paper on both sides, siliconised on one side
Front material Polymer PVC film
Adhesive Solvent-polyacrylate

General

Thickness 0.3 mm Average value, without protective liner and adhesive
Reflective Characteristics
Reflective Technology Prismatic
Reflectivity Compliance Reflective film structure: Design C
Reflectivity classes: RA2
Dimensions
Format Roll
Standard width 246 mm
Standard length 50 m

Downloads

Area

Technical documents



Our safety data sheets / product information consider the state of the SVHC list of 2025-01-21.
